StepScrew(quantity)Color

Torque

M2.5×6.5mm,wafter-head,nylon-coated(2)

Black0.392Nm

(4kgfcm)

Wheninstalling:Makesurethattheconnectorsareattachedrmlytothesystemboard.

Instep4,releasewirelessantennacablesfromthecableguides.

Wheninstalling:Makesurethatthecablesareattachedtothecableguidesrmly.

Attention:Whenyouroutethecables,makesurethattheyarenotsubjectedtoanytension.Tensioncould

causethecablestobedamagedbythecableguides,orawiretobebroken.

80HardwareMaintenanceManual
