SHARP Pen SoftwareOPERATION MANUALVersion 3.1Applicable models (as of September 2014) Available models differ according to region.PN-L series ( PN-L

10En Floating menuThe menu can be moved to any position.To move the menu, drag the background.Title bar is linked to pin / unpin.Touch to minimize th

11En Menu iconsSquare menuIcon Function PagePen 1 to Pen 3Handwriting.23EraserErase hand-drawn lines.25SelectSelect an object.31UndoCancel the immedia

12EClassic menu(1)(3)(7)(9)(11)(13)(15)(5)(2)(4)(8)(10)(12)(14)(6)Floating Menu (vertical)(1)(3)(7)(9)(11)(13)(5)(2)(4)(8)(10)(12)(14)(6)Floating Menu

13En Selecting functions and customizing icons (All Functions)From the “All Functions” list, you can select functions to be used and the icons that ar

14EIcon Function PagePrintPrintPrint Current SheetPrint the displayed sheet.45Print AllPrint all sheets.OtherImport images Paste an image le acquired

15ECustomizing the icons that appear in the classic menu and oating menuThese settings are shared by the classic menu and oating menu (horizontal an

16EDisplay methodn Window display (whiteboard mode) (full version only)The whiteboard can be displayed in a window. Touch the “Window” button ( ) on t

17ESaving dataData can be saved in the following le formats:File format DescriptionSWSX(Whiteboard le)Data is saved in SWSX format. The saved data c

18EOpening FilesOpening a whiteboard le / overlay board le1. Touch “Open” in the menu.2. Select the le opening method. “New”: Create a new board

19EAdding a board / changing the board to be edited1. Touch the “Board list” button ( ) on the toolbar.The board list appears.2. Add: Touch “+”.To a

2EIntroduction ...3Required Operating Environment ...

20En Changing the sheet by dragging the screenOnly when the screen magnication is Fit Width, a sheet can be changed by dragging.1. Touch “View” in t

21En Changing the sheet by referring to thumbnail images / Editing the sheetWhen “Sheet list” button ( ) on the toolbar is touched, thumbnails of each

22En Editing sheets from thumbnails (full screen view only)When a thumbnail on the sheet list is selected, the menu appears. Copy: Copies the selecte

23En Changing sheet size (whiteboard mode) (full version only)The sheet size can be enlarged or reduced. (Max. 3840 x 2160)1. Touch the thumbnail of

24En Changing the color and thickness of the penIf you touch the icon of the selected “Pen 1” to “Pen 3” again, the type, color, and thickness setting

25EErasing a drawn line1. Touch “Eraser” in the menu.2. With the pen touching the screen, move the pen.The part you move over is erased.TIPS• You c

26EDrawing shapesYou can draw shapes such as circles, rectangles and triangles.1. Touch “Drawing Object” in the menu.The gure or line / arrow settin

27EDrawing straight lines or arrows1. Touch “Drawing Object” in the menu.The gure or line / arrow settings menu appears.Select line or arrow to dis

28EInputting text1. Touch “Text” in the menu.2. Touch the position where text will be entered.3. Input text in the displayed text box.n Text setti

29EImporting and pasting an imageAn image le can be imported, and the current display can be pasted.Up to 50 items can be pasted on 1 sheet.n Inserti

3EThis software is intended to facilitate effective meetings and presentations.• Letters can be created directly so that the computer screen can be u

30ECapturing/saving a specied area1. Touch “Insert Image” in the menu.2. Touch “Screen Capture”.3. Drag the area which you want to capture.4. Chec

31EEditing an objectThe drawn lines and the images pasted on the board are handled in the software as an “object”.n Selecting an objectYou need to sel

32En Selecting multiple objectsSelecting objects by draggingYou can select a group of objects by dragging to create a rectangle around the objects.1.

33En Moving an objectYou can move an object by selecting the object and dragging it. (Page 31)TIPS• To manipulate multiple objects at once, follow th

34En Cutting an objectYou can cut an object and save it to the clipboard.1. Select an object. (Page 31)2. Select “Cut” from the expansion menu.TIPS•

35En Changing the order of objectsYou can change the order of the object placement.1. Select an object. (Page 31)2. Select the object placement from

36EUndo/redo operationTouching “Undo” cancels the preceding drawing or editing operation.Touching “Redo” repeats the operation canceled with the “

37En Enlarging the screen in whiteboard modeThe zoom methods below can be used in whiteboard mode.Double-click to enlarge the screen1. Touch “View” i

38EUsing multiple touch pens simultaneouslyA maximum of 4 3 button pens can be used to draw at once.To use this function, set “Touch Pen” to “3 Button

39ELaunching an External Application (Full version only)An external application can be added to allow the application to be launched while this softw

4ERequired Operating EnvironmentComputerPC/AT compatible computer able to output a resolution of 1920 x 1080. (CD-ROM drive required for software ins

40ESearching the Internet (Full version only)By specifying a keyword and a search engine, you can search the Internet while the software is running.n

41EImporting a Document as an Image (Pen Software Printer Driver) (Full version only)A document of any application can be converted into an image and

42EAcquiring an Image From a Multifunction MachineIf a SHARP multifunction machine is connected to the same network as the monitor/computer on which t

43EWhen a scanner or other TWAIN device is connected to the computer on which the Pen Software is installed, an image scanned on the TWAIN device can

44ELinking to Microsoft PowerPoint (Full version only)When the slideshow display of Microsoft PowerPoint is detected, a control toolbar that makes it

45EPrinting1. Touch “Print” in the menu.2. To print the current sheet, touch “Print Current Sheet”. To print all sheets, touch “Print All”.Set t

46EUsing a Secondary Display (Full version only)Applicable models (as of September 2014)PN-L series ( PN-L602B/PN-L603A/PN-60TA3/PN-L603B/PN-60TB3/PN-

47ECustomizing the SettingsYou can customize various settings of this software.The settings are the same in both whiteboard mode and overlay mode. How

48E(4) Dual-Touch GestureSet whether dual touch is enabled. When enabled, the following actions are possible:• “Zoom” can be used to change the shee

49En DefaultYou can change the default settings for the functions.TIPS• When this software is restarted or new boards are created / added, setting wi

5EPen Software modes and how to start the modesn Full versionTIPS• When changing the mode, touch the “Board list” button ( ) and add a new board. (Pa

50ETo change the default settings for each 3 button pen(1) Select the “Change default setting of each 3 button pen” checkbox.• Set “Menu” to “Square

51En View(1)(2)(3)(4)(5)(6)(7)(1) Mode when whiteboard is started (Full version only)Set whether the mode when the whiteboard opens is “Full Screen”

52En Sheet(1)(2)(3)(4)(1) Background color of new sheet Size of new sheet (Full version only)Set the background color and size used when sheets are

53En Other(1)(2)(3)(4)(5)(1) Send EmailMail Server Settings : Set your SMTP server name, SMTP port number, secure password authentication, user ID,

54EThe operations in this section require administrator privilege.Installing the Pen Softwaren Installing the Pen Software1. Exit all running softwar

55EInstalling the Network Scanner ToolThe Network Scanner Tool is used to acquire an image from a SHARP multifunction machine connected to the same ne

56EIntellectual Property Rights and Other Matters that Apply to This SoftwareLicense information for this softwareSoftware componentsThis software co

57EDisplay of licenses of software components used in this softwareRequirement to display licenseCopyright holders of some of the software components

V3.1 EN 14J(1)

6EOverlay modeThe board is shown as transparent.Your drawing will appear on the transparent board placed over the screen, so that you can write commen

7EScreen example: Whiteboard mode(2)(1)(3) (4)(5)(6)(7)(8) (9)(10)(11)(12)(1) IndicatorTouch the icon to launch the square menu. (Page 11)When multipl

8E(11) BoardWork area. You can write letters, draw lines, and paste images etc.The board can be displayed in 2 modes: whiteboard mode and overlay mode

9En Classic menuThe menu can be displayed in classic mode (large or small icon size).Pan window (Only appears in whiteboard mode.) (Page 37)Shows the
