LC-24DV510KLCD COLOUR TELEVISION OPERATION MANUALENGLISH50186854SHARP ELECTRONICS (Europe) GmbHSonninstraße 3, D-20097 HamburgSHARP CORPORATIONhttp://

English - 9 -LCD TV and Operating ButtonsFRONT and REAR VIEW Control buttons VIEW Control ButtonsP\V-AV1. Standby Off/On button2. TV/AV button3. Pro

English - 10 -Viewing the Connections - Side ConnectorsCI Slot is used for inserting a CI card. A CI card allows you to view all the channels that 1

English - 11 -Using USB InputsUSB ConnectionYou can connect a USB hard disk drive or USB • memory stick to your TV by using the USB inputs of the TV

English - 12 -Connecting to a DVD Player via Component Sockets (YPbPr) or Scart CableSome DVD players are connected through • COMPONENT SOCKETS (YPb

English - 13 -Connecting the LCD TV to a PCFor displaying your computer’s screen image on your LCD TV, you can connect your computer to the TV set.

English - 14 - If the TV will not be used for a long period i.e. • holidays, then unplug the power cord from the mains socket. Input SelectionOnce

English - 15 -Yellow button: Display EPG data in accordane with timeline schedule Blue button (Filter): Views fi ltering options. (RECORD): the TV wi

English - 16 -To cancel an already set recording, highlight that • programme and press the OK button and select the option “Delete Rec. Timer”. The

English - 17 -After all the available stations have been stored a channel list will be shown based on the broadcaster LCN press OK to accept this c

English - 18 -Manual Tuning HINT: This feature can be used for direct broadcast entry.Select • Manual Channel Scan from the Installation menu by us

English - 1 -ContentsFeatures ... 3Dear SHARP customer ...

English - 19 -Operating the Channel ListPress “• ” or “ ” button to select the channel that will be processed. Press “ ” or “ ” button to select a

English - 20 -Managing Stations: Sorting Channel ListYou can select broadcasts to be listed in the channel list. To display specifi c types of broadc

English - 21 -Play ( button): Starts the video playback.Stop ( button): Stops the video playback.Pause ( button): Pause the video playback.Rewind (

English - 22 -0..9 (Numeric buttons): The TV will jump to the fi le starting with the letter you input via the numeric buttons on your remote control

English - 23 -Note: Switching to a different broadcast or source; and viewing main menu are not available during the timeshifting.Instant RecordingI

English - 24 -The format being displayed in AUTO mode is completely independent of WSS information which could be included in the broadcast signal o

English - 25 -Confi guring Picture SettingsYou can use different picture settings in detail.Press “MENU” button and select the Picture icon by using

English - 26 -Confi guring Sound SettingsSound settings can be confi gured according to your personal preferences.Press “MENU” button and select the

English - 27 -Using a Conditional Access ModuleIMPORTANT: Insert or remove the CI module only when the TV is SWITCHED OFF.In order to watch certain

English - 28 -Language SettingsIn the confi guration menu, highlight the Language Settings item by pressing “ ” or “ ” buttons. Press OK and Language

English - 2 -SPECIAL NOTE FOR USERS IN THE U.K.The mains lead of this product is fi tted with a non-rewireable (moulded) plug incorporating a 5A fuse

English - 29 -Use “• ” or “ ” button to set. The timer can be programmed between Off and 2.00 hours (120 minutes) in steps of 30 minutes.Setting Pr

English - 30 -Hard Disk Info To view the details about the USB disk, highlight Hard Disk Info by using “” or “ ” key and press OK. USB disk informat

English - 31 -Menu Timeout: Changes timeout duration for menu screens.Scan Encrypted: When this setting is on, search process will locate the encryp

English - 32 -Note: Most TV stations use code 100 for their index pages.Coloured Buttons (RED/GREEN/YELLOW/BLUE)Your TV supports both FASTEXT and TO

English - 33 -Appendix A: PC Input Typical Display ModesThe display has a maximum resolution of 1920 x 1080. The following table is an illustration

English - 34 -Appendix C: Supported DVI ResolutionsWhen connecting devices to your TV’s connectors by using DVI converter cables (not supplied), you

English - 35 -Appendix E: Software Upgrade• Your TV is capable of fi nding and updating new software upgrades over broadcast channels. • For broadcas

English - 36 -Specifi cationsTV BROADCASTINGPAL/SECAM B/G D/K K’ I/I’ L/L’RECEIVING CHANNELSVHF (BAND I/III)UHF (BAND U)HYPERBANDNUMBER OF PRESET CHA

English - 37 -Dimensional Drawings00_MB60_[GB]_(01_TV)_1910UK_IDTV_PVR_BRONZE17_24942LED_YPBPR_ROCKER_10072636_50186854.indd 3700_MB60_[GB]_(01_TV

English - 38 -End of life disposal00_MB60_[GB]_(01_TV)_1910UK_IDTV_PVR_BRONZE17_24942LED_YPBPR_ROCKER_10072636_50186854.indd 3800_MB60_[GB]_(01_TV

English - 3 -FeaturesRemote controlled colour LCD TV.• Fully integrated Terrestrial digital TV (DVB-T - MPEG2) • HDMI connectors for digital video a

English - 39 -Detachable Stand Uninstallation MethodTo install the TV on the wall, fi rst of all, foot assembly should be removed. Unscrew the 4 scre

English - 40 -Screw DimensionsLDModel D L Item Number VESA Installation of the Screw LC-19LE510E LC-19LE510KØ4 30 475 x 75 (W x H)To the wallM4 18 4

English - 41 -ContentsFeatures ... 41General Properties...

English - 42 -Safety InformationCAUTIONDVD Player is a class 1 laser product. However this product uses a visible laser beam which could cause hazar

English - 43 -DVD Control Panel ButtonsA. Disc loaderB. Play / PausePlays/pauses the disc. When DVD menu (root menu) is active, this button function

English - 44 -General OperationYou can operate DVD, movie CD, music or picture CD’s content by using the proper buttons on your remote control. Bel

English - 45 -General PlaybackBasic PlayPress on the power button1. Please insert a disc to the loader.2. The disc will be automatically loaded and

English - 46 -PreferencesDEFAULTIf you choose RESET and press OK, the factory-presets are loaded. Parental level and parental password does not chan

English - 47 -Some functions ( Zoom etc) do not work• These functions are not available on the DVD.No picture• Have you pressed the correct buttons

English - 48 -Disc Types Compatible with This UnitDIGITAL AUDIODVDAUDIO-CDAudio+Video12 cmAudio12 cmAudio(xx xx.m p 3 )MP3-CDJPEGREADABLEPICTURE-CD

English - 4 -Important safety precautionsCleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean • the

English - 5 -Safety PrecautionsRead the following recommended safety precautions carefully for your safety.Power SourceThe TV set should be operated

English - 6 -LCD ScreenThe LCD panel is a very high technology product with about a million thin fi lm transistors, giving you fi ne picture details.

English - 7 -Package ContentsSLEEPSCREENPRESETSLANG.FAVEPGSWAPSOURCECDISP.SEARCHMODEINFOCHVRemote ControlLCD TVBatteries: 2 X AAAInstruction BookQui

English - 8 -Remote Control ButtonsStandby1. Image size / Zooms videos (in Media Browser 2. video mode)Sleep Timer3. Mono / Stereo - Dual I-II / Cur
