National Instruments Corporation 7-13 Multisim Component Reference Guide
Multiplexer truth table:
7.2.22 40192 (4-bit Dec Counter)
7.2.23 40193 (4-bit Bin Counter)
SELECT INPUTS OUTPUTS
Sa Sb A0 B0 O0
00XX 0
100X 0
101X 1
01X0 0
01X1 1
111X 1
11X1 1
1100 0
The 40192 device is a 4-bit synchronous up/down decade counter with a count-up clock
input (CPU), a count-down clock input (CPD), an asynchronous parallel load input (PL
),
four parallel data inputs (P0 to P3), an asynchronous master reset input (MR), four counter
outputs (O0 to O3), an active LOW terminal count-up (carry) output (TC
U) and an active
LOW terminal count-down (borrow) output (TC
D).
The 40193 device is a 4-bit synchronous up/down binary counter with a count-up clock
input (CPU), a count-down clock input (CPD), an asynchronous parallel load input (PL
),
four parallel data inputs (P0 to P3), an asynchronous master reset input (MR), four counter
outputs (O0 to O3), an active LOW terminal count-up (carry) output (TC
U) and an active
LOW terminal count-down (borrow) output (TC
D).
