Copyright © 2000, 2006 Integrated Design Tools, Inc. sshhaarrppVVIISSIIOONN™™ CCrroossss--ppllaattffoorrmm UUsseerr MMaannuuaall PPrrooggrraamm

sharpVISION™ Digital Camera sharpVISION™ User Manual 10 44.. IInnssttaalllliinngg tthhee sshhaarrppVVIISSIIOONN™™ ccaammeerraa This section speci

sharpVISION™ Digital Camera sharpVISION™ User Manual 11 4.3. Software Installation Windows 2000/XP Before installing the software make sure that the c

sharpVISION™ Digital Camera sharpVISION™ User Manual 12 4.4. Hardware installation The camera gets the necessary power from the computer via the fire-

sharpVISION™ Digital Camera sharpVISION™ User Manual 13 4.5. Camera lens adapter The camera is supplied with a standard C-mount. Alternatively,

sharpVISION™ Digital Camera sharpVISION™ User Manual 14 55.. sshhaarrppVVIISSIIOONN™™ ssttaanndd--aalloonnee pprrooggrraamm 5.1. Overview This app

sharpVISION™ Digital Camera sharpVISION™ User Manual 15 5.2. sharpVISION™ menu structure The X-Vision main menu bar contains the following options: Fi

sharpVISION™ Digital Camera sharpVISION™ User Manual 16 5.4. Save images Each acquired sequence may be opened and saved in a different format. 1. Fro

sharpVISION™ Digital Camera sharpVISION™ User Manual 17 5.5. Camera Menu The camera menu on the main menu offers an alternative to using the buttons p

sharpVISION™ Digital Camera sharpVISION™ User Manual 18 5.6. Camera Control The camera configuration parameters may be interactively changed by openin

sharpVISION™ Digital Camera sharpVISION™ User Manual 19 This parameter controls the speed at which the image data is read from the CCD. The supported

sharpVISION™ Digital Camera sharpVISION™ User Manual 2 Software Release 2.07 Document Revision October 2006 Products Information htt

sharpVISION™ Digital Camera sharpVISION™ User Manual 20 5.6.1. Set a region of interest (ROI) The sharpVISION camera has a Partial Windowing capabili

sharpVISION™ Digital Camera sharpVISION™ User Manual 21 5.7. Record Settings The Record Settings dialog box allows the user to select the recording pa

sharpVISION™ Digital Camera sharpVISION™ User Manual 22 Enable automatic save… If this option is selected, the program stores the images to the hard d

sharpVISION™ Digital Camera sharpVISION™ User Manual 23 5.8. View Menu Use the View menu to magnify the image, restore the original size (100% zoom) o

sharpVISION™ Digital Camera sharpVISION™ User Manual 24 66.. AAppppeennddiixx AA -- TTrroouubblleesshhoooottiinngg Some common troubleshooting

sharpVISION™ Digital Camera sharpVISION™ User Manual 25 77.. AAppppeennddiixx BB –– PPrroodduucctt SSppeecciiffiiccaattiioonnss 7.1. Camera Spec

sharpVISION™ Digital Camera sharpVISION™ User Manual 26 7.2. Spectral Sensitivity NOTE: optional cooling reduces the thermal noise at long exposures

sharpVISION™ Digital Camera sharpVISION™ User Manual 27 7.4. Trigger connector The camera generates image data that is sent to the host interface via

sharpVISION™ Digital Camera sharpVISION™ User Manual 28 7.5. Cables Included with the camera there are two cables: IEEE 1394 Data Cable This is a IEEE

sharpVISION™ Digital Camera sharpVISION™ User Manual 29 88.. AAppppeennddiixx CC -- IImmaaggee FFoorrmmaattss sharpVISION supports the image for

sharpVISION™ Digital Camera sharpVISION™ User Manual 3 Table of Contents 1. PRECAUTIONS...

sharpVISION™ Digital Camera sharpVISION™ User Manual 30 8.1.3. PNG Format PNG is an extensible file format for the lossless, portable, well-compressed

sharpVISION™ Digital Camera sharpVISION™ User Manual 31 8.1.8. Multi-page Raw Format (MRF) Multi-page Raw Format (MRF) is an uncompressed IDT proprie

sharpVISION™ Digital Camera sharpVISION™ User Manual 32 nWidth: width of each image in pixels. nHeight: height of each image in pixels. nBPP: number o

sharpVISION™ Digital Camera sharpVISION™ User Manual 33 typedef struct _RCIMG_HEADER { unsigned long nSize; // size of this header u

sharpVISION™ Digital Camera sharpVISION™ User Manual 4 8.1.6. BLD Format...

sharpVISION™ Digital Camera sharpVISION™ User Manual 5 11.. PPrreeccaauuttiioonnss 1.1. Cleaning the sensor IDT recommends that the sensor NOT be ma

sharpVISION™ Digital Camera sharpVISION™ User Manual 6 22.. WWaarrrraannttyy IDT, Inc. provides warrants to the original purchaser that, from the da

sharpVISION™ Digital Camera sharpVISION™ User Manual 7 33.. SSyysstteemm OOvveerrvviieeww 3.1. Introduction to the sharpVISION™ Camera The sharpV

sharpVISION™ Digital Camera sharpVISION™ User Manual 8 • Controlled exposure from 35 μsec up to 15 minutes in increments of 1μsec. • Fast inter-fram

sharpVISION™ Digital Camera sharpVISION™ User Manual 9 3.3. Software Development Kit Upon the installation of the sharpVISION software package several
