CD-E250E

Preparation for Use

System connections

! FM/AM loop aerial connection

Connect the FM/AM loop aerial to the ANTENNA socket.

Position the FM aerial wire and rotate the AM loop aerial for opti-

mum reception. Place the AM loop aerial on a shelf, or attach it to a

stand or a wall.

Notes:

Placing the aerial on the stereo system or near the AC power

lead may cause noise pickup. Place the aerial away from the ste-

reo system for better reception.

Do not connect the attached FM aerial to an external aerial as

this may cause trouble.

Installing the AM loop aerial:

AM loop aerial

Surround

speaker (right)

Surround

speaker (left)

FM aerial

Front

speaker (right)

Front

speaker (left)

Wall socket

(AC 230 - 240 V, 50 Hz)

< Assembling > < Attaching to the wall >

Wall Screws (not supplied)
