09/9/8 XL-DH259N EN

E-10

You can store 40 AM and FM stations in memory and

recall them at the push of a button. (Preset tuning)

Note:

The backup function protects the memorized stations for a

few hours should there be a power failure or the AC power

cord become disconnected.

Press the PRESET ( or ) button for less than 0.5

seconds to select the desired station.

The stations saved in the memory can be scanned

automatically. (Preset memory scan)

In this example, the clock is set for the 12-hour (AM 12:00)

display.

To conﬁrm the time display:

Press the CLOCK/TIMER button. The time display will

appear for about 5 seconds.

Note:

The “CLOCK” will appear or time will be displayed when

the AC power supply is restored after a power failure or

unplugging the unit. If incorrect, readjust the clock as

follows.

To readjust the clock:

Perform “Setting the clock” from step 1. If the “CLOCK”

does not appear in step 2, step 3 (for selecting the 12-hour

or 24-hour display) will be skipped.

To change the 12-hour or 24-hour display:

1 Perform steps 1 - 3 in “Tuning”.

2 Press the MEMORY button.

3 Within 30 seconds, press the PRESET ( or ) button

to select the preset channel number. Store the stations

in memory, in order, starting with preset channel 1.

4 Within 30 seconds, press the MEMORY button to store

that station in memory. If the “MEMORY” and preset

number indicators disappear before the station is

memorized, repeat the operation from step 2.

5 Repeat steps 1 - 4 to set other stations, or to change a

preset station. When a new station is stored in the

memory, the station previously memorized for that

preset channel number will be erased.

1 Press the PRESET ( or ) button for more than 0.5

seconds. The preset number will flash and the

programmed stations will be tuned in sequentially, for 5

seconds each.

2 Press the PRESET ( or ) button again when the

desired station is located.

1 Press the ON/STAND-BY button to enter the stand-by

mode.

2 While pressing down the FUNCTION button, press the

POWER ON/STAND-BY button until “TUNER CLEAR”

appears.

Listening to the radio (continued)

Presetting a station

To recall a preset station

To scan the preset stations

To erase entire preset memory

1 Press the ON/STAND-BY button to turn the power on.

2 Press the CLOCK/TIMER button.

3 Within 10 seconds, press the MEMORY button.

Press the or button to select 12-hour or 24-

hour display and then press the MEMORY button.

The 12-hour display will appear.

(AM 12:00 - PM 11:59)

The 12-hour display will appear.

(AM 0:00 - PM 11:59)

The 24-hour display will appear.

(0:00 - 23:59)

4 To adjust the hour, press the or button and

then press the MEMORY button. Press the or

button once to advance the time by 1 hour. Hold it

down to advance continuously.

5 To adjust the minutes, press the or button and

then press the MEMORY button. Press the or

button once to advance the time by 1 minute.

1 Clear all the programmed contents. [Refer to “Factory

reset, clearing all memory” on page 14 for details.]

2 Perform “Setting the clock” from step 1 onwards.

Setting the clock (Remote control

only)

USB

“AM 12:00”

“AM 0:00”

“0:00”

1 2 ... 6 7 8 9 10 11 12 13 14 15 16
