E-7

Setting the clock (Remote control

only) (continued)

To confirm the time display:

Press the CLOCK/TIMER button. The time display will

appear for about 5 seconds.

Note:

When power supply is restored after unit is plugged in again

or after a power failure, reset the clock (pages 6-7).

To readjust the clock:

Perform “Setting the clock” from step 1. If the “Clock” does not

appear in step 2, step 4 (for selecting the 24-hour or 12-hour

display) will be skipped.

To change the 24-hour or 12-hour display:

Listening to the iPod, iPhone or iPad

Made for:

●

iPod touch (4

generation)

●

iPod touch (3

generation)

●

iPod touch (2

generation)

●

iPod touch (1

generation)

●

iPod classic

●

iPod nano (6

generation)

●

iPod nano (5

generation)

●

iPod nano (4

generation)

●

iPod nano (3

generation)

●

iPod nano (2

generation)

●

iPhone 4

●

iPhone 3GS

●

iPhone 3G

●

iPhone

●

iPad

Caution:

Please update your iPod, iPhone and iPad unit to the latest

software version before using it. Please visit Apple’s

homepage to download the latest version for your iPod,

iPhone and iPad.

Notes:

●

Charging terminal for iPod, iPhone and iPad:

●

The message

“

This accessory is not made to work with

iPhone” or similar, may appear on the iPhone screen

when:

- battery is low.

- the iPhone is not properly docked (eg. slanting).

If this occurs, remove and re-dock the iPhone.

●

This product is made for iPhone. To prevent random

interference when iPhone is docked, the headphone

output is disabled, and “HP INVALID” will be

displayed.

You may also experience brief audio interference

during incoming calls.

●

The headphone output is switched off during inserting

iPod, iPhone and iPad unit. This is an Apple product

specification.

Note:

USB terminal does not support VIDEO out.

1 Press the ON/STAND-BY button to turn the power on.

2 Press the USB button on the remote control or

FUNCTION button repeatedly on the main unit to select

USB function.

3 Connect iPod, iPhone or iPad to the unit. “USB/iPod” will

appear.

4 Press

the /

(CD/USB

/ ) button to start playback.

Note:

Stop button ( ) is invalid during iPod, iPhone or iPad play-

back.

● Sound will only switch from iPhone to the main unit

after authentication process is completed in

approximately 10 seconds.

● Incoming calls will pause the playback.

● Once the calls are answered, the conversation can only

be heard through the built-in iPhone speaker. Turn on

the iPhone speaker or undock the iPhone to start

conversation.

6 To adjust the minutes, press the or button and

then press the ENTER button. Press the or

button once to advance the time by 1 minute. Hold it

down to advance the time by 5 minutes interval.

1 Clear all the programmed contents. [Refer to “Factory

reset, clearing all memory” on page 21 for details.]

2 Perform “Setting the clock” from step 1 onwards.

Condition DOCK USB

USB function NO YES

Other function YES NO

Stand-by YES NO

■ iPod, iPhone and iPad connection (USB

only)

Insert the connector to the iPod, iPhone or iPad.

2 Place the iPad to the stand for iPad.

3 Connect the iPod, iPhone or iPad to the unit via USB

connector.

■ iPod, iPhone or iPad playback (USB)

■ iPhone playback

iPad

Connector

iPad

Stand for iPad

USB

Track n umb e r

1 2 3 4 5 6 7 8 9 10 11 12 ... 21 22
