MISFEED REMOVAL

When the misfeed ( ) indicator blinks or blinks in the display, the unit will

stop because of a misfeed. If a misfeed occurs when using the SPF, a number may

appear in the display after a minus sign. This indicates the number of the originals

that must be returned to the original feeder tray after a misfeed. Return the required

number of originals. Then this number will disappear when copying is resumed or the

clear ( ) key is pressed. When the SPF misfeeds an original sheet, the unit will

stop and the SPF misfeed ( ) indicator will blink, while the misfeed ( ) indicator

will remain off. For a misfeed of originals in the SPF, see "D: Misfeed in the SPF (AL-

2040)" (p.68).

Open the multi-bypass tray,

and then open the side

cover.

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the illustration

below. If the misfeed ( ) indicator blinks, proceed to "A:

Misfeed in the paper feed area" (p.65).

If paper is misfed here, proceed to "A:

Misfeed in the paper feed area". (p.65)

If paper is misfed here, proceed to "B:

Misfeed in the fusing area". (p.66)

If the misfed paper is seen from

this side, proceed to "C: Misfeed

in the transport area". (p.67)
