2-2

LOADING PAPER

The message "ADD PAPER" or "OPEN TRAY AND ADD PAPER" will appear when paper runs out during operation.

Follow the procedure below to load paper.

Loading paper in paper tray 1

Pull out paper tray 1.

Gently pull the tray out

until it stops.

Load paper into the tray.

Load a stack of paper no

higher than the indicator

line (about 500 sheets of

the recommended paper

for color (21 lbs. or 80 g/

), or approximately

500 sheets of SHARP

standard paper (21 lbs.

or 80 g/m

)).

Gently push tray 1 into the machine.

Push the tray firmly all the way into the machine.

Set the paper type.

If you change the paper type, be sure to set the

paper type refer to "Setting the paper type" (page

2-11).

Loading paper in paper tray 1 is now

complete.

Changing the paper size in paper tray 1

The following paper size settings are available for paper tray1: 11" x 17" to 8-1/2" x 5-1/2" (A3 to A5), and "EXTRA"*

Use the following procedure to change the size as needed.

This is limited to square or rectangular paper, 11" x 17" to 8-1/2" x 5-1/2" (A3 to A5) size.

Pull out paper tray 1.

If paper remains in the tray, remove it.

Adjust the paper size slide to the paper

size.

Move the paper size

slide right or left to

indicate the paper size

being loaded.

If a special size paper is

loaded in the paper tray,

set the size slide to

"EXTRA" to inform the machine that a special size

paper has been loaded. (When AB-based size

paper is loaded, move the size slide to "EXTRA".)

Note that setting the size slide to "EXTRA" only

informs the machine that a special size of paper

has been loaded; it does not inform the machine of

the specific size. If you wish to inform the machine

of the specific size, follow the steps in "Setting the

paper size when an extra size is loaded" (page 2-

11). (If you do not set a size, part or all of the image

may not print.)

Adjust the guide plates A and B by

squeezing their lock levers and sliding

them to the paper size to be loaded.

The guide plates A and

B are slidable. Adjust

them to the paper size to

be loaded while

squeezing their lock

levers.

NOTES

● Do not use curled or folded paper. Doing so may cause a misfeed.

● For best results use paper supplied by SHARP. (See pages 2-9, 2-17.)

● When you change the paper type and size in paper tray 1, you must change the paper type and size settings as

explained in "Setting the paper type" (page 2-11).

● Do not place heavy objects or press hard on any tray which is pulled out.

NOTE

If you load a different size of the same type of paper,

you only need to change the position of the size slide

(see step 2 below); you do not need to change the

paper type.

WhaleII_general-copy_SEC.book 2 ページ２００４年９月１４日　火曜日　午前１１時４５分
