LOADING PAPER

The message "TRAY< >:Add paper." will be displayed when there is no copy paper in the selected paper tray.

(< > is the tray number.) Load paper in the indicated paper tray.

PAPER

For best results, use only SHARP recommended paper.

A5 (5-1/2" x 8-1/2") can be used in the upper paper tray but cannot be used in other trays (including trays in optional paper

feeding unit).

When making a large number of copies or prints using 90 g/m

(24 lbs.) paper, remove the output from the paper output tray

when about 100 pages have been printed. The output may not stack correctly if more than 100 pages are allowed to

accumulate.

The number of sheets of the paper which can be set changes with the weight of a paper.

Index

Paper that can be used for automatic 2-sided printing

(MX-M182D/MX-M202D/MX-M232D)

Paper used for automatic two-sided printing must meet the following conditions:

Paper type: Plain paper (special paper cannot be used.)

Paper size: Standard sizes (A3, B4, A4, A4R, B5, B5R, A5, 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R)

Paper weight: 56 g/m

to 90 g/m

(15 lbs. to 24 lbs.)

Special papers

Follow these guidelines when using special papers.

●

Use SHARP recommended transparency film and label sheets. Using other than SHARP recommended

paper may result in misfeeds or smudges on the output. If other than SHARP recommended media must be

used, feed each sheet one at a time using the bypass tray (do not attempt continuous copying or printing).

● There are many varieties of special paper available on the market, and some cannot be used with this

machine. Before using special paper, contact your authorised service representative.

● Before using other than SHARP recommended paper, make a test copy to see if the paper is suitable.

Paper tray type Paper type Size Weight Capacity

Paper tray

250-sheet paper

feed unit

2 x 250-sheet

paper

feed unit

Standard paper

Recycled paper

(5-1/2" x 8-1/2"

(Invoice))

(8-1/2" x 11" (Letter))

(8-1/2" x 13" (Foolscap))

(8-1/2" x 14" (Legal))

(11" x 17" (Ledger))

56 g/m

to 90 g/m

2 *2

(15 lbs. to 24 lbs.

)

250 sheets

(Load paper lower

than the line on the

tray)

Bypass tray Standard paper

Recycled paper

A6R to A3

(5-1/2" x 8-1/2" (Invoice)

to 11" x 17" (Ledger))

56 g/m

to 90 g/m

(15 lbs. to 24 lbs.)

100 sheets

Load one sheet of

paper each time on

the bypass tray.

Transparency film

Labels

Thick paper A6R to A4

(5-1/2" x 8-1/2" (Invoice)

to 8-1/2" x 11" (Letter))

129 g/m

to 200 g/m

(33 lbs. to 110 lbs.

)

Load one sheet of

paper each time on

the bypass tray.

106 g/m

to 128 g/m

(28 lbs. to 33 lbs.)

You can load multiple

sheets of paper on

the bypass tray.

A6R to A3

(5-1/2" x 8-1/2" (Invoice)

to 11" x 17" (Ledger))

91 g/m

to 105 g/m

(24 lbs. to 28 lbs.)

You can load multiple

sheets of paper on

the bypass tray.

Envelopes International DL

(110 mm x 220 mm)

International C5

(162 mm x 229 mm)

Monarch

(3-7/8" x 7-1/2")

Commercial 10

(4-1/8" x 9-1/2")

5 sheets
