Copying files for MFP driver installation.

After confirming the message in the "Welcome" window, click the

"Next" button.

A dialog box appears asking you to verify that the interface cable

is not connected to the MFP. Make sure that the interface cable is

not connected and click the "Next" button.

Click the "Next" button in the dialog box

showing the files to be copied for installation

of the MFP driver.

The setup program will start to copy the files.

In Windows 2000, if the following screen appears

while the files are being copied (the message

may appear more than once), click "Yes" in

Windows 2000.

The following screen appears when all of the

files for the USB interface connection have

been copied. If you are not using a parallel

interface cable for connection to the MFP,

please click the "No" button.

When the "The MFP driver installation is

complete." dialog box appears, click the "OK" button.

The Button Manager installer will start.

Begin installation of the Button Manager (This step will start if it

was selected in step 4).

After confirming the message in the "Welcome" window, click the

"Next" button.

Read the message in the "Please read the following information."

window, and then click the "Next" button.

When a message appears that lets you specify the location for the

software to be installed, click the "Next" button.

If the program displays "Do you want the Button Manager added to

Windows Startup?", check "Yes" and click the "OK" button.

The setup program will start to copy the files.

Click the "Finish" button when the message to inform you of the

completion of the installation appears.

The Sharpdesk installer will start.
