STATUS INDICATORS

MISFEED REMOVAL

Misfeed removal

Misfeed in a paper tray

Open the side cover.

NOTE:

If the transport area misfeed indicator is lighted, clear the transport

area first. (See below, “Misfeed in the transport area.”)

Remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

If the paper cannot be seen from the side, pull out the

paper tray and remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

Close the paper tray and the side cover.

●

Confirm that the indicator has gone out.

Misfeed in the transport area

Open the front cover.
