Image Projection

5 Press to temporarily turn

off the sound.

Note

• Pressing

again will turn the

sound back on.

Selecting the On-screen

Display Language

The on-screen display language of the projec-

tor can be set to English, German, Spanish,

Dutch, French, Italian, Swedish, Portuguese,

Chinese, Korean or Japanese.

1 Press .

• The menu will be displayed.

2 Press \ or | to select “Lan-

guage”.

3 Press ' or " to select the de-

sired language, and then press

4 Press .

• The desired language will be set as

the on-screen display.

-36
