035-000040-001 Page 1 of 18 DVA IOM 1.3 08-18-2014

DV SERIES

Magic Aire Fan Coil Unit – Sizes 04 through 10

Installation, Operation and Maintenance Manual

The Magic Aire® Fan Coil Unit is

designed for use in any air distribu-

tion system. It is easily adaptable to

most types of existing or new forced-

air heating systems, or it can be in-

stalled in an independent air cooling

system.

GENERAL

Immediately inspect each unit

for damage upon receipt. File any

damage claims with the freight carri-

er. Protect stored units from dam-

age. Do not stack more than two

high.

Use these instructions in conjunction

with other appropriate instructions,

including but not limited to those in-

structions supplied with the outdoor

unit (if applicable). Installation must

comply with all applicable local

codes.

Pay particular attention to

the following words:

NOTE–intended to clarify or

make installation easier.

CAUTION–given to prevent

equipment damage.

WARNING–to alert installer

that personal injury and/or

equipment damage may re-

sult if installation procedure

is not properly followed.

EXISTING DUCT WORK

The previously installed air distribution system

for heating requires close inspection to determine

its suitability for cooling. In general, heating sys-

tems designed for outside temperatures of zero

degrees or lower will need no alteration when used

for cooling. However, in southern sections of the

country, the existing heating duct work may have

to be modified to provide better air distribution and

insulation for cooling.

DUCT INSULATION AND VAPOR PROOFING

Properly installed heating supply ducts should

already have adequate insulation against exces-

sive heat loss. This same insulation should there-

fore be satisfactory in the summer to protect

against heat gain. However, depending on the

specific installation, it may be desirable to add to

the insulation.

All externally insulated duct work must have an

adequate vapor seal for summer operation. This is

particularly important where the duct is exposed to

highly humid conditions in such places as attic,

vented crawl spaces, unconditioned basements,

and utility rooms. The vapor seal prevents conden-

sation of moisture in the insulating material and

subsequent loss of its insulating value.

NOTE: Consult a qualified insulation contractor

to insure your system is properly insulated.

1 2 3 4 5 6 ... 17 18

Inhaltsverzeichnis

Seite 1 - DV SERIES

035-000040-001 Page 1 of 18 DVA IOM 1.3 08-18-2014DV SERIESMagic Aire Fan Coil Unit – Sizes 04 through 10Installation, Operation and Maintenance Manua

Seite 2

035-000040-001 Page 10 of 18 DVA IOM 1.3 08-18-2014ECM APPLICATION GUIDELINESDV units with ECM motor have 5 pre-programmed speeds to choose from. Whic

Seite 3 - Instructions

035-000040-001 Page 11 of 18 DVA IOM 1.3 08-18-2014Figure 7ECM Motor Option-Control Box ConnectionsTerminal Block “TB1”Terminal Block “TB2”

Seite 4

035-000040-001 Page 12 of 18 DVA IOM 1.3 08-18-2014Airflow Table-ECM Motor

Seite 5

035-000040-001 Page 13 of 18 DVA IOM 1.3 08-18-2014Airflow Table-ECM Motor

Seite 6

035-000040-001 Page 14 of 18 DVA IOM 1.3 08-18-2014Figure 8Service Clearances(Upflow)

Seite 7

035-000040-001 Page 15 of 18 DVA IOM 1.3 08-18-2014Figure 9Service Clearances(Downflow)

Seite 8

035-000040-001 Page 16 of 18 DVA IOM 1.3 08-18-2014THIS PAGE INTENTIONALLY LEFT BLANK

Seite 9

035-000040-001 Page 17 of 18 DVA IOM 1.3 08-18-2014AIR HANDLERS AND FANCOILSt ĂƌƌĂŶƚǇZĞŐŝƐƚƌĂƟŽŶĂŶĚ^ƚĂƌƚ-up ReportWarranty Registration Form: Compl

Seite 10

035-000040-001 Page 18 of 18 DVA IOM 1.3 08-18-2014DV Series Air Handling UnitInstallation, Operation and Maintenance Manual

Seite 11 - Terminal Block “TB2”

035-000040-001 Page 2 of 18 DVA IOM 1.3 08-18-2014THIS PAGE INTENTIONALLY LEFT BLANK

Seite 12 - Airflow Table-ECM Motor

035-000040-001 Page 3 of 18 DVA IOM 1.3 08-18-2014Topic PageSAFETY CONSIDERATIONS1, 5UNPACKING1INSTALLATION5Pre-installation5Floor Mounting5Ductwork6C

Seite 13

035-000040-001 Page 4 of 18 DVA IOM 1.3 08-18-2014THIS PAGE INTENTIONALLY LEFT BLANK

Seite 14 - Service Clearances

035-000040-001 Page 5 of 18 DVA IOM 1.3 08-18-2014INSTALLATION1. Remove all packing and foreign materialfrom unit.2. Check blower wheel for free rotat

Seite 15 - (Downflow)

035-000040-001 Page 6 of 18 DVA IOM 1.3 08-18-2014INSTALLATION OF CHILLED WATER LINES(with Chilled Water Coils)1. If the Fan Coil Unit is located wher

Seite 16

035-000040-001 Page 7 of 18 DVA IOM 1.3 08-18-2014INSTALLATION OF REFRIGERANT LINESSize and install refrigerant lines in accordancewith the condensing

Seite 17 - AIR HANDLERS AND FAN

035-000040-001 Page 8 of 18 DVA IOM 1.3 08-18-2014Figure 3PSC Motor OptionUnit WiringELECTRICAL CONNECTIONSPSC MOTOR: Figure 3 illustrates the interna

Seite 18 - DV Series Air Handling Unit

035-000040-001 Page 9 of 18 DVA IOM 1.3 08-18-2014Figure 4Access Panels Removed(PSC Motor option shown)Figure 5ECM Motor-Connection DetailJ Box(Replac
