6. Answering

Machine

6. Answering Machine Connection

Connecting an Answering Machine

If desired, you can connect an answering machine to your fax

machine's

TEL. SET

socket. This will allow you to receive both

voice messages and faxes when you are out.

Remove the seal covering the

TEL.

SET

socket.

Connect the answering machine's

telephone line socket to the

TEL.

SET

socket.

•

If desired, you can connect an

extension phone to your answering

machine's extension phone socket.

To answering machine's

telephone line socket.

all-Fo50A.book Page 67 Friday, October 1, 1999 5:32 PM
