User’s Manual 2-19
The Grand Tour
BD-Writer drive
The full-size BD-Writer drive module lets you record data to writable
CD/DVD/BD discs as well as run either 12 cm (4.72") or 8 cm (3.15") for
Tray type CD/DVD/BDs without using an adaptor.
BD-Combo drive
The full-size BD-Combo drive module lets you record data to writable
CD/DVD/BDs as well as run either 12 cm (4.72") or 8 cm (3.15") for Tray
type CD/DVD/BDs without using an adaptor.
The read speed is slower at the centre of a disc and faster at the outer
edge.
BD-ROM read 6 speed (maximum)
DVD ROM read 8 speed (maximum)
CD-ROM read 24 speed (maximum)
BD-R write 6 speed (maximum)
BD-R(DL) write 4 speed (maximum)
BD-RE write 2 speed (maximum)
BD-RE(DL) write 2 speed (maximum)
DVD-R write 8 speed (maximum)
DVD-RW write 6 speed (maximum)
DVD+R write 8 speed (maximum)
DVD+RW write 8 speed (maximum)
DVD-R DL write 4 speed (maximum)
DVD+R DL write 4 speed (maximum)
DVD-RAM write 5 speed (maximum)
CD-R write 24 speed (maximum)
CD-RW write 16 speed (maximum, Ultra-speed media)
The read speed is slower at the centre of a disc and faster at the outer
edge.
BD-ROM read 6 speed (maximum)
DVD-ROM read 8 speed (maximum)
CD-ROM read 24 speed (maximum)
DVD-R write 8 speed (maximum)
DVD-RW write 6 speed (maximum)
DVD+R write 8 speed (maximum)
DVD+RW write 4 speed (maximum)
DVD-R DL write 4 speed (maximum)
DVD+R DL write 4 speed (maximum)
DVD-RAM write 5 speed (maximum)
CD-R write 24 speed (maximum)
CD-RW write 16 speed (maximum, Ultra-speed media)
