Prepare Parts for Reassembly

MAINTENANCE MANUAL

Do Not Bend or Straighten a Damaged

Drive Axle Housing

WARNING

Replace damaged or out-of specication axle

components. Do not bend, repair or recondition

axle components by welding or heat-treating. A

bent axle beam reduces axle strength, affects

vehicle operation and voids Meritor’s warranty.

Seriouspersonalinjuryanddamagetocompo-

nents can result.

Always replace a damaged drive axle housing.

Do not bend or straighten a damaged housing,

which can misalign or weaken it,

and void warranty.

Removing Fasteners Secured with

Adhesive

Ifit is difcult to remove fasteners secured with

Dri-Loc, Meritor adhesive or Loctite 277 adhe-

sive, use the following procedure.

When you remove fasteners secured with adhe-

sive, slowly heat the fastener to 350°F (177°C).

Do not exceed this temperature, or heat fasten-

ers quickly. Damage to components can result.

1.Heatthe fastener for three to veseconds.

Try to loosen the fastener with a wrench. Do

not use an impact wrench or hit the fastener

with a hammer.

2. Repeat Step 1 until you can remove the

fastener.

New Fasteners with Pre-Applied Adhesive

NOTE:

To remove fasteners secured with pr-ap-

plied adhesive no need to wait for drying

1. Use a wire brush to clean the oil and dirt from

threaded holes.

2. Install new fasteners with pre-applied adhe-

sive to assemble parts. Do not apply adhe-

sives or sealants to fasteners with pre-ap-

plied adhesive, or to fastener holes.

3. Tighten the fasteners to the required torque

value for that size fastener. See the warnings

to the required torque

Original or Used Fasteners

1. Use a wire brush to clean the oil, dirt and old

adhesive from all threads and threaded holes.

NOTE:

There is no drying time required for Meritor

liquid adhesive 2297-C-7049, Loctite 638 or

680 liquid adhesive or equivalent.

2.Apply four or ve drops of Meritor liquid ad-

hesive Loctite 638 or 680 or equivalent inside

each threaded hole or bore. Do not apply adhe-

sive directly to the fastener threads. Figure 4.9.

3. Tighten the fasteners to the required torque

value for that size fastener. See the warnings

to the required torque.

Meritor Aplication Adhesive 2297-T-

4180 in the Differential Bearing Bores

NOTE:

UseMeritorspecication2297-T-4180adhe-

sive, for all axles.

Cuatro o cinco gotas

en las roscas

Figure 4.9

9. For complete welding instructions, refer to

Maintenance Manual 8, Drive Axle Housings.

To obtain this publication, see to the Service

Notes page on the brgin this manual.
