6-6

10.

Replace the hard disk slot cover and tighten two screws.

Hard Disk Slot Cover

Screws

11.

Turn on the computer and check the memory size with the procedure in the

previous section.

Uninstalling the Memory Module

Follow steps 1-5 above.

Slightly bend the two latches outward until the memory module is released.

Remove the memory module and follow steps 9-10 above.
