Wireless installation

Use the wireless LAN USB adapter supplied with the

TV.

Wireless connection overview





Wireless LAN router/access point



Wireless LAN USB adapter (supplied)



Network

NOTE

• When using the SHARP wireless LAN USB adapter

(supplied), try to provide as much free space around the

device for best performance.

• Make sure the firewalls in your network allows access to

the TV wireless connection.

• Operations cannot be guaranteed when used with

access points that do not have Wi-Fi® certification.

• A wireless LAN access point is required to connect

the TV to the Internet using a wireless LAN. See the

operation manual of your access point for setup.

How to connect

1 Switch on your router before starting the

network installation.

2 Connect the wireless LAN USB adapter

(supplied) to the USB 3 (WIRELESS LAN) port on

the rear of the TV.

• Do not use a wireless LAN adapter other than

the supplied SHARP wireless LAN adapter, as

operations cannot be guaranteed.

3 Go to “Menu” > “Setup” > “View setting” >

“Network setup” > “Connection type”.

4 Press c/d to select “Wireless”, and then press

5 Select “OK” to confirm.

6 Press a/b to select “Wireless setup” in the

“Network setup” menu.

7 Press c/d to select “Change”, and then press

8 Press a/b to select “WPS”, and then press

WPS

Manual Setup

• If your router/access point does not support WPS

(= Wi-Fi Protected Setup), select “Search” and

follow the on-screen instructions and the operation

manual of the router/access point.

• To establish the connection manually, select

“Manual setup” and follow the on-screen

instructions and the operation manual of the router/

access point.

9 Press a/b to select “Push button”, and then

press ;.

Push button

PIN code

• To establish the connection manually, select “PIN

code”. Follow the on-screen instructions and the

operation manual of the router/access point.

Select “Next” to proceed.

Press the WPS button on the router/access

point. When you press the WPS button, a

progress bar will appear on the display. Wait

until the connection is established.

Select “OK” when the connection details are

displayed.

• If you have failed to connect to the internet in the

above operation, an error message will appear. In

this case, press ATV/DTV/SAT/b to return to the

normal TV screen and check the relevant settings.

NOTE

• To connect your TV to the internet, you must have a

broadband internet connection.

• If you do not have a broadband internet connection,

consult the store where you purchased your TV or ask

your internet service provider or telephone company.

• There is no need to enter the security key for

subsequent connections to the wireless network.

• If your access point is set to a stealth mode (that

prevents detection by other devices), you may not be

able to establish a connection. In this case, disable the

stealth mode on the access point.

• If you want to change the IP settings manually, go to

“Menu” > “Setup” > “View setting” > “Network setup” >

“IP setup” and follow the on-screen instructions and the

operation manual of the router.

• See page 79 to check the supplied SHARP wireless LAN

adapter specifications.

Network setup
