Loveland Fire/Rescue

Pumper

Production Specification

SVI #769 Page 60 of 125 June 17, 2010

..\4) Pricing & Change Orders\Production Change Order.pdf

HEADLIGHT AND MARKER LIGHT ACTIVATION

The headlights and marker lights shall be controlled via a virtual button on the Vista display. There shall be a virtual

dimmer control on the Vista display to adjust the brightness of the dash lights.

GROUND LIGHTS

Each door shall include an incandescent NFPA compliant ground light mounted to the under side of the cab step below

each door. Each light shall include a polycarbonate lens, a housing which is vibration welded and a bulb which shall be

shock mounted for extended life. The ground lighting shall be activated by the opening of the door on the respective cab

side, when the parking brake is set and through the Vista screen.

STEP LIGHTS

The middle step located at each door shall include a NFPA compliant 4.00” round incandescent light which shall activate

with the opening of the respective door.

Each light shall produce 21 candle power of illumination and draw 1.5 amps.

ENGINE COMPARTMENT LIGHT

There shall be an incandescent NFPA compliant light mounted under the engine tunnel for area work lighting on the

engine. The light shall include a polycarbonate lens, a housing which is vibration welded and a bulb which shall be shock

mounted for extended life.

SIDE SCENE LIGHTS

The cab shall include two (2) Fire Research model LED900-Q65 surface mount lights, one (1) each side. Each light shall

be 6.75 inches high X 9.00 inches wide and have a profile of less than 1.75 inches beyond the mounting surface. Wiring

shall extend from a weatherproof strain relief at the rear of the light.

Each lamp head shall have twenty-four (24) white LEDs that generate a rated 4400 lumens at 12 or 24 volts DC. The lens

shall redirect the light along the vehicle and out onto the working area. The light housing shall be aluminum with a chrome

colored bezel.

SIDE SCENE LIGHT LOCATION

The scene lighting located on the left and right sides of the cab shall be mounted rearward of the cab “B” pillar in the

10.00 inch raised roof portion of the cab between the front and rear crew doors.

SIDE SCENE ACTIVATION

The left and right side scene lights shall be activated by opening the respective side door and by individual virtual buttons

on the MUX display(s) in the cab.
