Loveland Fire/Rescue

Pumper

Production Specification

SVI #769 Page 98 of 125 June 17, 2010

..\4) Pricing & Change Orders\Production Change Order.pdf

ZONE A - FRONT WARNING LIGHT

There shall be one (1) Code 3 model 2169NFPA1, 69" long lightbar permanently mounted on cab roof.

Lightbar Configuration (streetside to curbside):

Section

Components

Color

1

(3) LED X Single Module with Directional Optics

Red LED/ Clear Lens

2

(1) LED X Single Module with Directional Optics

Red LED/ Clear Lens

3

(1) LED X Single Module with Wide Optics

Red LED/ Clear Lens

4

(1) LED X Single Module with Directional Optics

Red LED/ Clear Lens

5

(1) LED X Single Module with Wide Optics

Red LED/ Clear Lens

6

(1) LED X Single Module with Wide Optics

Red LED/ Clear Lens

7

(1) LED X Single Module with Wide Optics

Red LED/ Clear Lens

8

(1) LED X Single Module with Directional Optics

Red LED/ Clear Lens

9

(1) LED X Single Module with Wide Optics

Red LED/ Clear Lens

10

(1) LED X Single Module with Directional Optics

Red LED/ Clear Lens

11

(3) LED X Single Module with Directional Optics

Red LED/ Clear Lens

All clear lights shall shut down when the parking brake is set to comply with "Blocking" mode requirements as outlined in

NFPA 1901.

The lightbar shall be separately switched at the vista display in the cab.

GTT OPTICOM

One (1) GTT Opticom emitter light shall be provided inside specified light bar. The Opticom shall be activated with light

bar and de-activated when the park brake is set and the vehicle is in blocking mode.

ZONES B AND D - SIDE WARNING LIGHTS

UPPER REAR CORNER WARNING LIGHTS

ZONE C - REAR WARNING LIGHTS

Two (2) Code 3 model TR-3RS Triad LED beacon lights shall be provided in the rear upper zone of the body. There shall

be one (1) light mounted on each side, near the corners of the body. Each light shall have three (3) Optix LED light

modules, synchronized/alternating flash pattern, wide optics lenses, and a triangular black coated aluminum housing.

The lights shall be switched at the Vista display in the cab.

The beacons (TR-3RS) shall have red LED light modules.
