Clearing Paper Jams

130

Clearing Paper Jams

Clearing a jammed document

If the original document doesn’t feed properly during transmission or copying,

or [DOCUMENT JAMMED] appears in the display, first try pressing . If

the document doesn't feed out, remove it as explained below.

START

1 Open the operation panel.

2 Rotate the lever toward you and down, and then pull the lever (➊) and

right end of the roller up (

➋). Remove the document (➌).
