(K) USB connector (A type)
(L) USB connector (B type)
(M) LAN connector
The part indicated in the illustration is only
to be handled by a service technician.
(J) Power plug
(I) Original placement position on the document glass
Mark Mark
8-1/2" x 11" or A4
8-1/2" x 14"
or B4
11" x 17" or A3
5-1/2" x 8-1/2"
or A5
B5
8-1/2" x 11"R or A4R
B5R
