CHANGING PAPER IN A TRAY

Names of the trays

The names of the trays are shown below.

For the number of sheets of paper that can be loaded in each tray, see the following manuals:

• System Settings Guide, "Paper Tray Settings"

• Safety Guide / Troubleshooting, "SPECIFICATIONS"

Print side face up or face down

When loading paper in a tray, the print side is loaded face up or face down depending on the tray.

Trays 1 to 4

Load the paper with the print side face up.

However, if the paper type is "Pre-Printed" or "Letter Head", load the paper with the print side face down*.

Bypass tray and tray 5

Load the paper with the print side face down.

However, if the paper type is "Pre-Printed" or "Letter Head", load the paper with the print side face up*.

* If "Disabling of Duplex" is enabled in the system settings (administrator), load the paper in the normal way (face

up in trays 1 to 4; face down in the bypass tray and tray 5).

(6) (5)

(1)

(2)

(3)

(4)

(1) Tray 1

(2) Tray 2

(3) Tray 3

(4) Tray 4

(5) Tray 5 (large capacity tray)

(6) Bypass tray
