1. Connecting the Projector

to a Computer

Establishing a one-to-one connection from

the projector to a computer. Using a

commercially available LAN cable (UTP

cable, Category 5, cross-over type) you can

conﬁgure the projector via the computer.

Disconnect the computer's LAN

cable from the existing network.

Connect a commercially available

LAN cable (UTP cable, Category 5,

cross-over type) to the projector's

LAN terminal and connect the

other end of the cable to the

computer's LAN terminal.

Plug the power cord into the AC

socket of the projector.

Turn on the computer.

Info

Conﬁrm that the LINK LED on the rear of the

projector illuminates. If the LINK LED does not

illuminate, check the following:

• The LAN cable is properly connected.

• The power switches of both the projector and

the computer are on.

A LAN cable being

connected to the network

LAN cable

(cross-over type, commercially available)

This completes the connection. Now proceed to “2. Setting an IP Address for the Computer”.
