Useful Features

When no input signal is detected for more than 15

minutes, the projector will automatically shut off.

(Slide the MOUSE/ADJUSTMENT switch

on the remote control to the ADJ. position.)

1 Press MENU.

2 Press ß/© to select “Options”.

3 Press ∂/ƒ to select “Auto Power Off”.

4 Press ß/© to select the “ ” or “ ”.

5 Press ENTER to save the setting.

6 To exit from the GUI, press MENU.

(GUI) On-screen Display

Automatic Power Shutoff Function

2, 3, 4

1, 6

Projector Remote control

MOUSE

ADJ.

On-screen Display

• The on-screen message on the left will appear five minutes

before the power is automatically turned off.
