PORTABLE LIFTERINSTRUCTION BOOKSAFETYMODELCM-270H1CM-340H1CM-520H1

K.S.F.4. The Portable Lifter is equipped with Level Device. (Exception Model CM-270H1).Checking if it's in the condition of leveling before raisi

K.S.F.2. The Portable Lifter should be stored on a flat surface. DO NOT place heavyobjects on it. If stacking, please handle it according to the instr

K.S.F.5. LEGENDPLATFORMTELESCOPING MASTCASTINGPULLEY WITH PULLEY COVERSTEEL CABLEMOTOR AND GEARBOXSLIDE RINGLEGS11～ ～

K.S.F.6. SET UP1. Take off the belt mounted on the mast.2. Loosen the screw of Slide Ring andexpending the LEGS.3. Tighten the screw of Slide Ring.4.

K.S.F.7. Put the Platform on and tighten the screwbelow to fixed it. Take off the belt andunfold the platform.6. Model CM-340H1, CM-520H1 equipped wit

K.S.F.～ ～149. OPTIONAL FUNCTION FOR CM 520H1 :CM-520H1 have optional function for work against the wall.Shift the pin from the forth leg to lock the h

K.S.F.1. Check before operation1-1 Before plugging, please make sure the voltage is right.1-21-31-4This is not damaged, it because the gearin the gear

K.S.F.1. Shift the LEVER to UPmark side of the switch box andpress the TRIGGER to raising.2.3.RAISING:LOWERING: Shift the LEVER to DOWNmark side of th

K.S.F.YES!! RIGHT!!NO!! WRONG!!THE AUTOMATIC OVERLOAD BREAKER STARTED IS SOUND LIKE" DA. DA. DA. DA", AND THE PORTABLE LIFTER WILL STOP RAIS

K.S.F.9. EMERGENCY STOP BUTTON , MANUALLY1. When the unexpect situation is happening,press the emergency stop button, themachine will stop raising or

CERTIFICAT CE ou DECLARATION DE CONFORDirective CE 98/37 avec modification CE 98/79K.S.F.Suivant la réglementation CE - Machine ce document est appelé

K.S.F.10. DISASSEMBLY1. Fold the platform and put the belton.2. Loosen the screw below the platformand lift the platform off the cylinder.3. Loosen th

K.S.F.11. ORDINARY EXAMINATIONNo.POSITION ITEMSTOOLSRESULTRESOLUTIONTelescopingMast1.2.LubricationSteel Cable Tearingor frayed.1. Check the mastis Lub

K.S.F.K.S.F.12. APPENDIXSpecificationModelSpecificationCM-270H1 CM-340H1 CM-520H1Current110V Or 220V110V-8A , 220V-4AVoltage3.5M↑ 90KGS3.5M↓120 KGSLoa

K.S.F.～ ～22K.S.F.13. Explode View of Motor and Gearbox

K.S.F.～ ～23K.S.F.Explode View of CM-340H1

K.S.F.～ ～24K.S.F.Explode View of CM-520H1

◎ /2009.07 Copyright by KSF.

WARNING SYMBOLTo maintain the operation safety of this machine, the user shall read the includedcautions in this manual very carefully to make sure of

If there is any condition of taking off or damage, assure to change it at once.Only the qualified personnel is allowed to install and use this equipme

We are very appreciated for your adopting CM Series of Portable Lifter. Our company isthe team insisted in High Quality and Excellent Technology to ma

K.S.F.INDEX～ ～51. PRECAUTIONS & WARNING----------------------------------------------- 62. TRANSPORTING THE PORTABLE LIFTER-----------------------

～ ～6K.S.F.HAZARDSThis instruction book shall be put in an easily accessible location for all users.1. DO NOT use this equipment to life people or as a

K.S.F.1 DO NOT lower the load unless the area below is clear of personnel and obstructions.14. DO NOT place ladder or scaffolding against any part of

K.S.F.4.Keep the work space and surroundings clean and tidy. Working in dirty or darksurroundings could cause an accident.5. DO NOT operate the machin
