MAKING COPIES

Unfold the bypass tray.

●

When feeding 8-1/2" x 14" or 11" x 17" sized paper, extend the bypass

tray.

Set the paper guides to the copy paper width.

Insert the copy paper (print face down) all the way into

the bypass tray.

●

Up to 100 sheets of standard copy paper measuring from 5-1/2" x

8-1/2" to 11" x 17" can be loaded in the bypass tray.

●

Transparency film, labels, and other special purpose papers (except

envelopes) must be fed individually.

Up to 10 envelopes can be set.

●

When adding paper, first remove remaining paper, combine it with the

paper to be added and then reload as a single stack.

●

When loading envelopes, make sure that they are straight and flat.

Bypass feed (special paper)

BYPASS FEED (special paper)

The bypass tray is used to copy onto transparency film, labels, and other

special purpose papers. Up to 100 sheets of standard copy paper can be set

in the bypass tray.

For special purpose papers, the original image must be

smaller than the paper or media for copying.

If the original image is bigger than the paper or media, this

may cause smudges on the edges of the copies.

Also for standard copy paper, smudges may appear if the

copy paper is not at least as large as the original image.
