TROUBLESHOOTING

B. Misfeed in the fusing area

Push gently on both ends of the front

cover.

Turn the roller rotating knob in the

direction of the arrow.

Carefully remove the misfed paper.

Lower the fusing unit release levers to

allow easier removal.

Be careful not to tear the

misfed paper during

removal.

Lift the fusing unit release levers, to

return them to their operating

position.

Close the front cover and side cover.

The misfeed indicator

( ) will go out.

The fusing unit is hot. Do not touch

the fusing unit when removing misfed

paper. Doing so may cause a burn or

injury.

• Do not touch the photoconductive drum

(green portion) when removing the misfed

paper. Doing so may damage the drum and

cause smudges on copies.

• Be careful about unfixed toner on the

misfed paper not to soil your hands or

clothes.

Roller rotating knob

Fusing unit

release lever

Warning

Caution

• When closing the front cover, gently hold

both ends.

• When closing the side cover, press on the

handle.

• If the misfeed indicator ( ) does not stop

blinking, check for torn pieces of paper in

the machine.

Note
