Sharp AR-163 Spezifikationen PDF herunterladen (Seite 30)

STATUS

INDICATORS

Open the bypass tray. Lift slightly on the side cover and

slide the cover out until it stops.

Push gently on both sides of the front cover to open the

cover.

Push the toner cartridge lock release lever and pull the

toner cartridge out. Remove the toner cartridge while

supporting it with the left hand at the green label position.

●

For disposal of the old toner cartridge, contact your dealer.

Remove the new toner cartridge from the bag. Hold the

cartridge on both sides and shake it horizontally four or

five times.

TONER CARTRIDGE REPLACEMENT

When the toner cartridge replacement required ( ) indicator lights up,

replacement of the toner cartridge will be needed soon. Obtain a new

cartridge.

When the toner cartridge replacement required ( ) indicator blinks, the

toner cartridge must be replaced before copying can be resumed. Replace

the toner cartridge by following the procedure below.

For best copying results, be sure to use only

SHARP products.

The package of SHARP toner has the Genuine

Supplies label.

Toner cartridge replacement

Toner cartridge lock

release lever

4 or 5 times

GENUINE SUPPLIES

During a long copy run of a dark original, the

indicator may blink and the copier stop, even though

toner is left. The copier will feed toner up to 2 minutes

and then the START key ( ) indicator will light up.

Press the START ( ) key to restart copying.
