TRANSPARENCY

SPECIAL FUNCTIONS

Load transparency film into the bypass tray.

●

Load transparency film one sheet at a time in the portrait orientation.

Make all other desired copier selections and press the START ( )

key.

●

To cancel the transparency feature, highlight "TRANSPARENCY" with a check mark on

the SPECIAL MODES screen and press the OK key.

Ar-M208_sec.book 66 ページ２００２年６月１３日　木曜日　午後２時３７分
