NORMAL COPYING
4-9
4
■
■■
■ Copy output (sort and group)
Example: Making five sets or five copies each of three originals
●
●●
● Sorting copies into sets
●
●●
● Grouping copies by page
■
■■
■ Selecting the output tray (when an optional finisher or saddle stitch finisher is
installed)
When the [OFFSET TRAY] key is highlighted, output pages are delivered to the offset tray of the finisher or
saddle stitch finisher. When the "CENTRE TRAY" key is highlighted, output pages are delivered to the centre
tray. Touch the appropriate key to select the desired output tray.
This screen appears when a saddle stitch finisher is installed.
The screen that appears when a finisher is installed is slightly different.
SPECIAL MODES
2-SIDED COPY
OUTPUT
OUTPUT
SORT
GROUP
Original
Press the [START]
key
Set the
number of
copies (5)
Touch the
[OUTPUT] key
Touch the
[SORT] key
Five sets of copies
When using the automatic document feeder, sorting is
automatically selected when the original is placed in the
document feeder.
SPECIAL MODES
2-SIDED COPY
OUTPUT
OUTPUT
SORT
GROUP
Press the [START]
key
Set the
number of
copies (5)
Touch the
[OUTPUT] key
Touch the
[GROUP] key
"Group" is automatically selected when the
original is placed on the document glass.
5 copies per page
Original
OUTPUT
SORT
GROUP
STAPLE
SORT
OFFSET
TRAY
CENTRE
TRAY
OFFSET
PUNCH
SADDLE
STITCH
OK
0
Copy_EX.book 9 ページ ２００４年９月２８日 火曜日 午後９時５４分
