CALLING UP AND USING A FILE
7-17
7
■ [Print]
A saved file can be printed.
The screen below appears when the [PRINT] key is selected in the operation selection screen. To begin printing,
touch the [PRINT] (7) key. Printing settings can be selected in this screen before printing. The settings that were
in effect when the file was saved appear initially. The settings can be changed as needed.
(1) [PAPER SELECT] key
Use this key to set the paper size.
(2) [OUTPUT] key
Use this key to select sort, group or staple sort
functions, and to select the output tray.
(3) [2-SIDED] key
When performing two-sided printing, use this key to
select the orientation of the image on the back side
of the paper. To have the front and back images
oriented in the same direction, touch the [2-SIDED
BOOKLET] key. To have the front and back images
oriented opposite to each other, touch the [2-
SIDED TABLET] key. Note that the size and
orientation of the saved image may cause these
keys to have the opposite effect. If neither key is
selected, one-sided printing will take place.
To perform two-sided printing, the optional duplex
module is necessary.
(4) [TANDEM PRINT] key
If the conditions for tandem printing are met (page
5-10), touch this key to enable tandem printing.
See page 5-10 for more information.
When printing a file that was saved in copy mode,
this key changes to the [SPECIAL MODES] key.
The [SPECIAL MODES] include [PRINT MENU]
and [TANDEM PRINT]. For information on the print
menu, see page 5-30.
(5) [NUMBER OF PRINTS] setting key
Use this key to set the number of copies.
(6) [PRINT AND DELETE THE DATA] key
Touch this key to print a file and then have it
automatically deleted.
(7) [PRINT AND SAVE THE DATA] key
Touch this key to print a file. The file will not be
automatically deleted after printing.
NOTES
● When print settings are changed with this procedure, only the value for the number of copies is overwritten.
● The printing speed will be slower for image files saved using certain resolution settings. (See page 7-31.)
PRINT AND DELETE THE DATA
PRINT AND SAVE THE DATA
NUMBER OF PRINTS
CANCEL
1
(1~999)
PAPER SELECT
TANDEM PRINT
2-SIDED
OUTPUT
AUTO
JOB SETTINGS / PRINT
Basic specifications
Yamada Taro
8 x11
1
/
2
SPECIAL MODES
2-SIDED
(1)
(2)
(4) (5) (6) (7)
(3)
