SPECIAL MODES

5-5

Dual page copy

The dual page copy function produces separate copies of two documents placed side by side on the document glass.

This function is especially useful when copying books and other bound documents.

[Example] Copying right and left pages of a book

Touch the [DUAL PAGE COPY] key on the

special modes screen.

The [DUAL PAGE

COPY] key will be

highlighted to indicate

that the function is

turned on, and the dual

page copy icon ( ) will

appear in the upper left

of the screen.

Touch the [OK] key on the special modes

screen.

You will return to the main screen of copy mode.

Place the originals on the document glass.

When copying a thick

book, press down lightly

on the book to flatten it

against the document

glass.

Place the opened original on the document glass so

that the first page you wish to copy is on the right and

the center of the original is aligned with the size mark.

Ensure that 8-1/2" x 11" (A4) size paper is

selected.

If 8-1/2" x 11" (A4) size

paper is not selected,

touch the [PAPER

SELECT] key to select

8-1/2" x 11" (A4) size

paper.

●The dual page copy function can be used only

when copying from the document glass. The

automatic document feeder cannot be used with

this function.

●Only 8-1/2" x 11" (A4) paper can be used.

Book original Dual page copy

To display the special modes screen...

See "General procedure for using special

functions" on page 5-2.

RASE

1/3

DUAL PAGE

COPY

JOB

BUILD

TANDEM

COPY

Index

11" x 17"

Center line of

original

This page

is copied

first.

8 " x 11"

8 "

x 11"

(A4) (A3)

About the steps that follow

For two-sided copying, follow steps 2 through 4

on page 4-13 and then follow steps 4 through 6

on page 4-12.

For one-sided copying, follow steps 4 through 6

on page 4-12.

NOTE

To erase shadows caused by document binding, use

the edge erase function (page 5-4). (Center Erase

and Edge + Center Erase cannot be used in

combination.)

To cancel the dual page copy function, touch the

[DUAL PAGE COPY] key on the special modes

screen (screen of step 1).

AUTO

100%

8 x11

PAPER SELECT

COPY RATIO

EXPOSURE

Copy_SEC.book 5 ページ２００６年１２月１３日　水曜日　午後３時１分
