LOADING PAPER

2-10

■ Loading transparency film

Be sure to load the transparency film with the white label side up. Make sure no image will be printed on the label.

Printing on the label may cause smudges on prints. Transparency film must be set in the portrait orientation.

Specifications (multi purpose drawer)

Specifications are subject to change for improvement without notice.

Loading paper in the stand/3 x 500 sheet paper drawer

Upper paper tray:

The upper tray is the same as the multi-purpose drawer. Use the upper tray according to the instructions for the

multi-purpose drawer on page 2-8.

Middle and lower paper trays:

Up to 500 sheets of SHARP recommended plain paper can be loaded in these trays. The method of loading paper

is the same as for paper tray 1 in the main unit. See the description (page 2-2).

Specifications (stand/3 x 500 sheet paper drawer)

Name Multi purpose drawer

Paper size/weight See specifications of paper trays on page 2-3.

Paper capacity

500 sheets (20 lbs. (80

g/m

)) of paper, 40 envelopes, 40 postcards, 40 sheets

of transparency film

Dimensions

25-3/4" (W) x 22-21/64" (D) x 5-43/64" (H)

(654 mm (W) x 567 mm (D) x 144 mm (H))

Weight Approximately 24.3 lbs. or 11 kg

NOTE

If the paper size or paper type is changed in either paper tray, the tray settings must be changed in system settings.

Refer to "

Setting the paper type and paper size" on page 2-5.

Name Stand/3 x 500 sheet paper drawer

Paper size/weight See specifications of paper trays on page 2-3.

Paper capacity

(ordinary paper)

500 sheets (20 lbs. (80

g/m

)) each

Dimensions

23-3/16" (W) x 24-51/64" (D) x 15-29/32" (H)

(589 mm (W) x 630 mm (D) x 404 mm (H))

Weight Approximately 70.6 lbs. or 32.9 kg

02-1.fm 10 ページ２００６年１２月１３日　水曜日　午後４時３分
