100

Remove all pieces of tape shown in the illustration below. Then

open the SPF and remove protective materials. After that, take

out the bag containing the TD cartridge.

Release the scan head locking switch.

The scan head locking switch is under the document glass.

If the switch is locked (

)

, the unit will not operate. Unlock the switch ( )

as shown below.

Lock Unlock

Grasp here and turn in

the direction of the arrow.
