CODE: 00ZARPB2A//1EDIGITAL COPIER OPTIONPRINTER UNITMODEL AR-PB2AThis document has been published to be usedfor after sales service only.The contents

(3) Engine Spec.Maximum Paper Size A3, 11" x 17"Print Resolution 600 x 600 dpiSmoothing YesToner Save Print YesPhoto Enhancement YesEngine S

Dutch 801 SWM *1Dutch 801 Italic SWM *1Dutch 801 Bold SWM *1Dutch 801 Bold Italic SWM *1Symbol SWAWingbats SWMLine Printer *2Dutch 801™ SWADutch 801 I

[3] SETUP1. Parts listBefore installing the printer kit, check that all the following items are prepared.Be careful that the necessary parts depend on

• The installation work after this step varies with the shapeof the rear cabinet.• If the rear cabinet is a box type, proceed to step 9.• If the rear

10) Remove the securing screws holding the P side OP cover in therear lower cover which was removed in the step 2, then removethe P side OP cover.Next

C. Network environment (Network card installation)1) Insert the network card into the network card slot on the printercontrol PWB. and fix it with scr

B. Checking the Hardware and SoftwareRequirementsTo use the NW Setup, the following hardware and software areneeded.NetWare server: IntranetWare (NetW

[4] SETTING AND ADJUSTMENT1. Configuration setting(Accessing the Printer Configuration Menu)To access the printer configuration menu, follow thesteps

A. Printer Settings Use the printer settings when printing without the proper printer driverinstalled (for example, printing from an MS-DOS applicatio

D. Print Test PagePrinting a test page verifies that the printer operates properly. Alsoyou can check the configuration settings, built-in fonts etc.

CONTENTS[ 1 ] SYSTEM CONFIGURATION . . . . . . . . . . . . . . . . . . . . .1-11. Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3. Hardware setup and adjustmentsA. Flash Memory write protect settingFlash memory write protect setup (JP109)Used to setup write protect YES/NO of fl

[5] Configuration Report and Test Page1. Samples2. Description of Each contentsThis section defines the meaning of each item. These items are basi-cal

Hardware Specsa. Base MemoryValue: 16 MBExample: 16 MBDefault: 16 MBDescription: It indicates base memory quantity of the printer board.Basically, thi

b. Large Capacity TrayValue: [Appropriate Paper Size]Example: Letter (81/2x11)Default: Depends on paper tray configuration.Description: It indicates p

[6] FIRMWARE VERSION UP1. Printer controll PWBA. Cases where flash memory rewriting is requiredIn the following cases, the program in the printer cont

[7] FUNCTION AND OPERATION1. Multi FunctionMultiple FunctionsArbitration of contention among printing, copying and faxing is controlled by the copier.

2. Printer Operation / Message DisplayState Display JOBCancel/(Clear)Paper SelectionOnlineLEDDataLEDDuring initializing the printer board <Display

3. Emulation SwitchEmulation setting can be switched between automatic emulationsensing (switching) and fixed emulation modes as shown below.AR-PB2Aut

Setting BehaviorAutomatic SwitchingBetweenJobsWhen receiving data is detected througha port, sensing data receipt from eachport, considers the port as

15. Confidential PrintThe confidential print feature allows printing to be started only afterentering the specified password on the operation panel. T

[1] SYSTEM CONFIGURATION1. HardwareA. Main Unit (1) Print Controller Hardware and OptionsController HardwareHardware configuration is as follows:• P

(Error message)F9 0 Content ICU-PRT communication troubleDetailCause SCSI LSI abnormalityICU PWB defectSCSI connector connection defectPrinter PWB de

CONTENTSPARTS GUIDEAR-PB1/PB1AMODEL AR-PB2/PB2A(Printer unit)(Printer PWB)(Packing material & Accessories)(Index)SHARP CORPORATIONThis document h

DEFINITIONThe definition of each Rank is as follows and also noted in the listA : Parts necessary to be stocked as High usage parts.B : Parts necessar

1 (Printer unit)2 (Printer PWB)NO. PARTS CODEPRICE RANKNEWMARKPARTRANKDESCRIPTIONEx. Ja.1AD DJ CPWB holder (SRF5U)2 AD DJ CCap (JM-2W-96) [JP109]3 AG

2 (Printer PWB)NO. PARTS CODEPRICE RANKNEWMARKPARTRANKDESCRIPTIONEx. Ja.45AN EG BIC (FCT244ATS0) [IC101,148] IC46CB TX BIC (GT64010AP1) [IC125] IC47BA

3 (Packing material & Accessories)NO. PARTS CODEPRICE RANKNEWMARKPARTRANKDESCRIPTIONEx. Ja.13AQ EQ DOperation manual (English)(Australia,New Zeal

(Index)PARTS CODEJAPAN ONLYORDER CODENO.PRICE R.NEW P/REx.Ja. 3- 13 AQ EQ D 3- 13 AQ EQ D 3- 13 AT EZ D 3- 13 AT EZ N D 3- 13 AT EZ N D 3- 13 AV FG

PARTS CODEJAPAN ONLYORDER CODENO.PRICE R.NEW P/REx.Ja. 2- 65 AA DD C 2- 66 AA DD C 2- 67 AA DD C 2- 68 AA DD C 2- 69 AA DD C 2- 70 AA DD C 2- 71 AA DD

AR-PB2A

ADVARSEL !Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering.Udskiftning må kun ske med batteriaf samme fabrikat og type.Levér det brugte batte

D. Accessory and OptionsPart name Model Q’ty NoteAccessories SCSI cable 1Wire saddle 1Band 1Printer box installing screw 5Printer control PWB 1 With f

SHARP CORPORATIONDigital Document Systems GroupQuality & Reliability Control CenterYamatokoriyama, Nara 639-1186, Japan2000 April Printed in USAAl

2. Software ConfigurationWin3.1x/Win95/WinNT4.0ApplicationGDI (Graphic Module)Print SpoolerOthersPostScriptPCL(SPDL)PCL6(EX only)Printer Driver1284 Po

[2] SPECIFICATIONNew function provided by combination use with AR-287/337/407/507• Confidential Print• Tandem Print• E-mail Status/E-mail Alerts• Pote

2. Printing Function SpecificationA. Outline(1) WindowsFunction PCL5e custom driver PCL6 custom driver PS custom driver PPD file *1General Copies 1-99

Function PCL5e custom driver PCL6 custom driver PS custom driver PPD file *1Graphic Resolution Setting 600dpi ←←←Halftone Setting N/A Photo imageLine

Function Macintosh PPD fileFont Resident Font 35 fontsCategory 1In font chapterDownload Font N/AOthers ConfigurationSettingYesWatermark N/AForm Overla
