Connecting the parallel interface cable

Obtain an IEEE1284 shielded parallel interface cable.

Ensure that your computer and unit are turned off.

Insert the cable into the parallel

interface connector located on the

rear of the unit, and fasten with

clasps.

Insert the other end of the cable into the interface connector of

your computer.
