3-2

SENDING THE SAME DOCUMENT TO MULTIPLE

DESTINATIONS IN A SINGLE OPERATION

(BROADCAST TRANSMISSION)

This feature is used to send a document to multiple destinations in a single operation. The document to be transmitted

is scanned into memory and then successively transmitted to the selected destinations. This feature is convenient for

such purposes as distributing a report to company branches in different locations. Up to 300 destinations can be

selected. When transmission to all destinations has been completed, the document is automatically cleared from

memory.

NOTES

• If you frequently use broadcasting to send documents to the same group of destinations, it is convenient to program those

destinations into a group key. A group key is a one-touch key in which multiple destinations are programmed. The procedure

for programming group keys is explained on page 6-6.

• When using a group key to send a fax, the destinations programmed in the group key are counted as broadcasting destinations.

For example, if five destinations are programmed in a group key and the key is touched for a broadcast transmission, the

broadcast transmission will have five destinations.

Beep

The document is scanned

into memory

Reception

Destination A

(recipient)

Successive

transmission

Beep

Sender

Destination B

(recipient)

Destination C

(recipient)

Successively enter

destination numbers

100%

PTION

ADDRESS

DIRECTRY

SUB ADDRESS

NEXT ADDRESSSE
