5-27
5
SADDLE STITCH FINISHER
Stapling position quick reference guide for duplex output
The orientation of the copy paper, original, scanned original data, and binding position selection are all interrelated.
The table below shows these relationships.
Orientation of original or original data
Output result
Page 1 Page 2
Page 1 & Page 2
Duplexed
One-position stapling Two-position stapling
One-position stapling Two-position stapling
One-position stapling Two-position stapling
Two-position staplingOne-position stapling
One-position stapling
One-position stapling
Left binding with two-position
stapling cannot be made.
Right binding with two-
position stapling cannot be
made.
Top binding with two-position
stapling cannot be made.
Two-position stapling along
the shorter edge cannot be
made.
Two-position stapling along
the shorter edge cannot be
made.
Two-position stapling along
the shorter edge cannot be
made.
Right binding
Right binding
Top binding
Top binding
Left binding
Left binding
Portrait orientation printing
Landscape orientation printing
