GETTING STARTED

Changing the copy paper size in the tray

Gently lift and pull out the paper tray until it stops.

Push the pressure plate down until it locks in place.

Squeeze the lock lever of the front guide and slide the

front guide to match the width of the paper.

Move the left guide to the appropriate slot as marked

on the tray.

●

A5 copy paper cannot be used in the lower paper tray of AR-5120.

Load copy paper into the tray.

Place the appropriate label to indicate the selected

paper size into the recess on the right front side of the

paper tray.

Push the paper tray firmly back into the copier.

Loading copy paper

LOADING COPY PAPER

Front guide

Left guide
