GENERAL INFORMATION

USER PROGRAMS

User programs

Select the desired parameter using the numeric keys.

●

The entered parameter number will blink on the right side of the copy

quantity display.

●

The parameters are shown in the table below.

For example, to change the setting of the auto power shut-off timer to

60 min., press key 2.

If you select “0” (OFF) in a program, the corresponding

function will be disabled.

Press the START ( ) key.

●

The right-hand number in the copy quantity display will be steadily lit

and the entered value will be stored.

To continue with other user programs, press the key

and then repeat steps 2 to 5. To exit the user program

mode, press the light ( ) key.

●

All the alarm indicators will go out.

Program name Parameters

Auto clear time 0 OFF 1 30 sec. * 2 60 sec. 3 90 sec. 4 120 sec.

5 10 sec.

Preheat mode 0 OFF 1 30 sec. 2 60 sec. * 3 90 sec. 4 120 sec.

Auto power shut-off timer * 1 30 min. 2 60 min. 3 90 min. 4 120 min. 5 240 min.

Stream feeding mode * 0 OFF 1 ON

Auto power shut-off setting 0 OFF * 1 ON

Auto paper select mode 0 OFF * 1 ON

Auto tray switching 0 OFF * 1 ON

●

Factory default settings are indicated with an asterisk (*).
