7-19
CHAPTER7
OPTIONAL EQUIPMENT
Finisher (AR-FN4)
FINISHER (AR-FN4)
FINISHER (AR-FN4)
The AR-FN4 finisher provides an offset stack mode of the output for
both copying and printing. A staple print mode is provided for the print
mode only and will not function in the copy mode.
PART NAMES
Staple cartridge
Finisher release lever
Offset tray
Pull out the tray extension
when 8-1/2" x 14" or
larger paper is to be output.
Specifications
Paper Ordinary Face-up Non offset: 1,000 sheets 5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, 8-1/2" x 11",
capacity/size paper 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
(16~28 lbs.) 700 sheets 8-1/2" x 13", 8-1/2" x 14"
500 sheets 11" x 17", 12" x 18"
Offset: 1,000 sheets 5-1/2" x 8-1/2", 8-1/2" x 11", 8-1/2" x 11"R
700 sheets 8-1/2" x 13", 8-1/2" x 14"
500 sheets 11" x 17"
Face-down Non offset: 1,000 sheets 5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, 8-1/2" x 11",
(*For printer 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
use) 700 sheets 8-1/2" x 13", 8-1/2" x 14"
500 sheets 11" x 17", 12" x 18"
Offset: 1,000 sheets 5-1/2" x 8-1/2", 8-1/2" x 11", 8-1/2" x 11"R
700 sheets 8-1/2" x 13", 8-1/2" x 14"
500 sheets 11" x 17"
Heavy paper* Face-up Non offset: 10 sheets 8-1/2" x 11", 8-1/2" x 11"R, 11" x 17"
(*Transparency
film)
Paper weight Face-up 16-75 lbs.
Face-down 17-34 lbs.
(*For printer
use)
Offset 0.8 inches (20 mm)
Paper size for stapling 5-1/2" x 8-1/2", 8-1/2" x 11", 8-1/2" x 11"R, 8-1/2" x 13", 8-1/2" x 14",
(*For printer use) 11" x 17"
Stapling capacity* 20 sheets 5-1/2" x 8-1/2", 8-1/2" x 11", 8-1/2" x 11"R, 8-1/2" x 13",
(*For printer use /for 28 lbs. paper) 8-1/2" x 14"
15 sheets 11" x 17"
Power supply 24V, 2.5A Max. 6.5A (drawn from the copier)
Weight Approx. 30.9 lbs. (14kg) *without mounting kit
Dimensions 20.3"(W) x 22.6"(D) x 15.0"(H) *without mounting kit
(515mm(W) x 574mm(D) x 381mm(H))
Specifications are subject to change for improvement without notice.
