ROUTINE MAINTENANCE

CLEANING THE BYPASS TRAY PAPER FEED

ROLLER

If misfeeds occur frequently when feeding envelopes, thick paper, etc. through the bypass tray, wipe the paper feed

roller at the feed slot of the bypass tray with a soft, clean cloth dampened with alcohol or water.

CLEANING THE TRANSFER CHARGER

If copies start becoming streaky or blotchy, the transfer charger may be dirty.

Clean the charger using the following procedure.

Turn the power switch off.

Open the bypass tray and the side

cover.

Lift and pull out the upper paper tray.

Take the charger cleaner out by

holding the tab.

Set the charger cleaner onto the

transfer charger and gently slide the

cleaner in the direction indicated by

the arrow two or three times.

If the white sheet metal is

smudged with toner,

wipe it with a soft, clean

cloth.

Return the charger cleaner to its

original position. Close the upper

paper tray. Close the side cover by

pressing the handle on the cover.

Turn the power switch on.

Paper feed roller

Charger

cleaner

Slide the charger cleaner from one end to the

other end along the groove of the transfer

charger. If the cleaner is stopped on the way,

smudges on copies may occur.

Note
