81
PROGRAMMING
6
[EDITING AND DELETING F-CODE RELAY
GROUPS]
9
Select "CHANGE" or "DELETE" with
the [ ] or [ ] key.
10
Press the [OK] key.
• If you selected "CHANGE" in step 9, follow the steps
in "Editing an F-code relay group" which follows.
• If you selected "DELETE" in step 9, follow the steps
in "Deleting an F-code relay group" which follows.
● Editing an F-code relay group
11
Select the name of the F-code relay
group (box) that you wish to edit with
the [ ] or [ ] key.
If not all letters of the box name appear, press the
key to display all letters. Press the key once again
to return to the original screen.
12
Press the [OK] key.
13
Edit the name of the F-code relay
group (box) (see "ENTERING
CHARACTERS" on page 84).
• See step 9 on page 78.
• If you do not wish to edit the name, go to the
next step.
14
Press the [OK] key.
15
Edit the sub-address and passcode
(maximum 20 digits) with the numeric
keys.
• See steps 3 to 6 on page 67.
• If you do not need to edit the sub-address and
passcode, press the [OK] key and go to the
next step.
16
Edit the relay destinations.
See steps 13 to 15 on page 78.
● Deleting an F-code relay group
11
Select the name of the F-code relay
group (box) that you wish to delete
with the [ ] or [ ] key.
If not all letters of the box name appear, press the
key to display all letters. Press the key once again
to return to the original screen.
12
Press the [OK] key.
13
Select "DELETE" with the [ ] or [ ]
key.
14
Press the [OK] key.
You will return to step 11. If you
wish to delete another relay
group, repeat steps 11 through
14. To exit, press the [BACK]
key.
GH
PQR
DUPLEX
SPECIAL FUNCTION
DUPLEX SCAN
S.A. RELAY GRP
CHANGE
DELETE
GHI
OK
BACK
GH
PQR
DUPLEX
SPECIAL FUNCTION
DUPLEX SCAN
S.A. RELAY GRP
SBC CO.
— — — — — —
— — — — — —
[#]:LIST DETAIL
GHI
OK
BACK
OK
GH
PQR
DUPLEX
SPECIAL FUNCTION
DUPLEX SCAN
S.A. RELAY GRP
SBC CO.
— — — — — —
— — — — — —
[#]:LIST DETAIL
GHI
OK
BACK
OK
Pegasus-E_Fax_Sec.book 81 ページ ２００４年９月２４日 金曜日 午後２時５１分
