Broadcasting
69
5. Special
Functions
• Enter one or more full fax numbers
(max. of 20) with the numeric keys,
pressing the
START
key after each
full number.
• Press one or more Group Keys.
(See
Storing numbers in Group
Keys
at the end of this section.)
4
Press the
START
key.
The display will show:
BROADCAST MODE
SELECT THE MODE
• If desired, adjust the resolution and/
or contrast.
5
Press the
START
key twice.
Transmission will begin.
• A Transaction Report is
automatically printed out after
Broadcasting is completed. Check
the "Note" column of the report to
see if any of the locations are
marked "Busy" or have a
communication error code. If so,
send the document to those
locations again.
RESOLUTION
Q
CONTRAST
START
START
all-FO4700.book Page 69 Friday, June 11, 1999 1:57 PM
