Print Hold

5. Special

Functions

Clearing the Print Hold code

Follow the steps below if you need to clear the Print Hold code.

Note: To clear the Print Hold code, the Print Hold function must first be turned

off as explained on the previous page.

1 Press .

2 Press .

3 Press the numeric keys to enter the Print Hold code.

4 Press .

PRINT HOLD

START/

ENTER

Display:

PRINT HOLD

ENTER #(1-4, , )

3:PRT. HOLD CODE CLR

ENTER PASSCODE #
