Large capacity tray

The paper size of tray 5 can only be changed by a service technician.

Gently pull out the paper tray.

Insert the paper with the print side face

down.

Fan the paper well before inserting it.

Otherwise, multiple sheets may feed at

once and cause a misfeed.

Insert the paper and then gently push the

tray into the machine.

Indicator line

The indicator line indicates the maximum

height of the paper that can be loaded in

the tray. When loading paper, make sure

that the stack is not higher than the

indicator line.

Do not load as shown below.

01-1_Quick(General).fm 22 ページ２００８年５月２８日　水曜日　午後７時１６分
