BEFORE USING THE PRODUCT
1
(13) [FAX] key / indicator (when the fax option is
installed)
LINE indicator, DATA indicator
This key is used in fax mode. For more
information, see the "Operation manual (for
facsimile)" that accompanies the optional
facsimile expansion kit.
(14) [SPECIAL FUNCTION] key
Press to select special functions.
(15) [EXPOSURE] key
Use to select the exposure mode. "AUTO",
"TEXT", or "PHOTO" can be selected. (Page 48)
(16) [PAPER SELECT] key
Use to manually select a paper tray. (Page 49)
(17) [COPY RATIO] key
Press to select a reduction or enlargement copy
ratio. (Page 52)
(18) [AUTO IMAGE] key
Press to have the copy ratio selected
automatically. (Page 52)
(19) [OUTPUT] key
Use to select the sort function. (Page 64)
(20) [2-SIDED COPY] key (only on models that
support two-sided printing)
Select the two-sided copying mode. (Page 56)
(21) Arrow keys
Press to move the highlighting (which indicates
that an item is selected) in the display.
(22) [ACC.#-C] key ( )
Press the end the use of an account and return
the display to the account number entry screen.
(Page 23)
(23) [0] key
Press during a continuous copy run to display the
number of copies completed.
(24) [READ-END] key ( )
When copying in sort mode from the document
glass, press this key when you have finished
scanning the original pages and are ready to start
copying. (Page 64)
(25) [CA] key
Clears all selected settings and returns the
machine to the default settings. (Page 18)
(26) [START] key ( ) / indicator
Copying is possible when this indicator is on.
Press the key to start copying. This indicator
blinks when auto power shut-off mode has
activated. Press the key to return to normal
operation.
ABC DEF
JKLGHI MNO
TUVPQRS WXYZ
@.-
_
READ-END
ACC. #-C
BACK
OK
INTERRUPT
COPY RATIO
ADDRESS
ADDRESS
DUPLEX SCAN
DUPLEX SCAN
2-SIDED COPY
PAPER SELECT
RESOLUTION
RESOLUTION
AUTO IMAGE
FORMAT
BROADCAST
OUTPUT
ORIGINAL SIZE
ORIGINAL SIZE
(6) (8)(7) (9) (10) (11) (12)
(16) (17) (18) (19) (20) (21) (26)(25)(24)(22) (23)
Pegasus-E_Copy_Ex.book 15 ページ ２００９年７月２２日 水曜日 午後２時４分
